1、 Inspection before operation of oil fume purifier:

1、該設備必須專人負責，操作，維修及保養；

1. The equipment must be operated, repaired and maintained by special personnel;

2、操作人員需進行培訓，獲得上崗證必須持證上崗，并學習油煙凈化器《使用說明書》，了解該設備的基本結構和性能，熟練掌握操作規程，并嚴格按照操作規程進行操作；

2. Operators shall receive safety training, obtain work license and work with certificate, and learn the Operation Manual of the fume purifier, understand the basic structure and performance of the equipment, master the operating procedures, and operate in strict accordance with the operating procedures;

3、油煙凈化器用電量大，為防止導線超負荷，須采用單獨線路供電，同時安裝合適的熔斷器和使用耐高溫的絕緣材料并加裝漏電保護器；

3. The oil fume purifier consumes a large amount of electricity. In order to prevent the overload of the conductor, it is necessary to use a separate line for power supply, and at the same time, install appropriate fuses, use high-temperature insulation materials and install leakage protectors;

4、開機前應認真點檢設備防護裝置是否良好，設備接地線是否牢固，電源系統及艙門是否關閉是否密封良好；排油管是否接好；

4. Before starting the machine, carefully check whether the safety protection device of the equipment is in good condition, whether the grounding wire of the equipment is firm, and whether the power supply system and cabin door are closed and sealed; Whether the oil drain pipe is connected properly;

5、確認輸入電壓與設備使用電壓是否匹配；

5. Confirm whether the input voltage matches the equipment use voltage;

6、為確保，油煙凈化器要求能與風機聯動，及凈化器跟風機同時開同時關；如不能聯動的，應做到啟動凈化器之前必須先啟動風機運行10分鐘；（特別是在北方嚴寒的冬天，風機先啟動的時間應該，關機時應先關掉凈化器后再停風機；

6. To ensure safety, the oil fume purifier is required to be linked with the fan, and the purifier and the fan are opened and closed at the same time; If linkage is not possible, the fan must be started for 10 minutes before starting the purifier; (Especially in the cold winter in the north, the fan should be started first, and the purifier should be turned off before the fan is shut down;

7、油煙凈化器與煙罩出口位置的距離少2米以上，以確保消防和凈化效果；凈化器與風機的距離4米以上比較合適；

7. The distance between the oil fume purifier and the outlet of the hood shall be at least 2 meters to ensure the fire safety and purification effect; The distance between purifier and fan is more than 4 meters;

二、油煙凈化器操作程序：

2、 Operating procedures of oil fume purifier:

1、完成通電前檢查正常后，開啟風機電源控制開關，當凈化器電源批示箱，綠燈亮?xí)r，表示凈化器已開始正常運轉工作；

1. Turn on the fan power control switch after completing the check before power-on. When the green light in the purifier power instruction box is on, it means that the purifier has started normal operation;

2、如啟動后，若紅燈偶爾有閃爍，表示電極間有放電現象，屬正?，F(xiàn)象；

2. If the red light flashes occasionally after starting, it means that there is discharge between electrodes, which is normal;

3、若紅燈長時間亮著，表示不工作，可按動電箱復位鍵多次，如綠燈亮?xí)r，表示已恢復正常工作；

3. If the red light is on for a long time, it means that it does not work. You can press the reset button of the electric box several times. If the green light is on, it means that it has resumed normal work;

4、如紅燈長時間亮著，按動復位鍵多次亦未轉綠燈，應關閉電源，重新檢查電極控制電路，確定無誤后，再次啟動電源開關。如反復操作紅燈亮?xí)r，則再次關閉電源開關，對高壓電極進行檢杳，清洗，同時亦可聯系維修技術人員及進檢修；

4. If the red light is on for a long time, and the reset button is pressed several times without turning green, the power should be turned off, the electrode control circuit should be rechecked, and the power switch should be started again after confirming that there is no error. If the red light is on after repeated operation, turn off the power switch again, check and clean the high-voltage electrode, and also contact professional maintenance technicians for maintenance;

三、油煙凈化器運行使用注意事項：

3、 Precautions for operation and use of oil fume purifier:

1、由于油煙凈化器內屬高壓系統，嚴禁設備在通電的工作狀態下，打開電極艙門和電控箱門，以及觸摸設備內一切系統部件；

1. Since the oil fume purifier is a high-voltage system, it is strictly prohibited to open the electrode cabin door and the electric control cabinet door, and touch all system components in the equipment when the equipment is powered on;

2、嚴禁任何異物進入設備電極系統內；

2. No foreign matter is allowed to enter the electrode system of the equipment;

3、設備箱體必須接地；

3. The equipment box must be grounded safely;

4、本設備不允許非人員拆裝及檢修，若發生故障時，應及時關閉電源，由人員進行檢修；

4. The equipment is not allowed to be disassembled and repaired by non-professional personnel. In case of failure, the power supply shall be turned off in time and the equipment shall be repaired by professional personnel;

5、油煙凈化器使用2~3個月內，必須對設備進行清洗、保養、否則出現故障導致影響處理效率；

5. The oil fume purifier must be cleaned and maintained within 2~3 months of use, otherwise the failure will affect the treatment efficiency;
